Model: UN1260G
Applications: Advertising signs, logo making, decorative products, production of advertising and a variety of metal materials and other metal fabrications industry
Leadtime: 15-20 working days
Certifications: CE ISO
Voltage: AC380V/50HZ/3phase
Customized: YES
Warranty: 12 month
Supply Ability: 50 sets/ month
Overseas service team: Portugal, UK, America
E-mail: melinda@uneedcnc.com
-widely used for all kinds of metal cutting, like carbon steel, stainless steel, aluminum, copper, galvanized steel plate, etc.
-Professional for wide and thick metal cutting
-Economic price with large cutting thickness and fast speed
-With USB interface, no need to connect to computer, easy to learn and operate
-the whole structure welded by 20# and 8# heavy industry steel, with aging treatment and high temperature quenching treatment, linear reference surface finishing by Precision milling machine , sandblasting and polishing
Pills, painted surface
-fast speed and large cutting capability
-Support Wentai, Astronautics Haire, ARTCAM softwares, Type3 produce standard G code way document, also can change software to read AUTOCAD softwares produce DXF form documents.
# CE certificate
#Working area: 12000*6000*200mm (Optional: 12000*4000/12000*8000mm)
# Huayuan LGK200A power*2 sets (Optional: LGK100,120,200,200)
# XF300 cutting torch* 2 sets
# Bilateral drive
# FL2300B control system with remote control
# Japan Panasonic servo * 4 sets
# Shimpo Reducer
# Lifting device for Z axis* 2 sets
# THC-400PT pressure arc height controller
# rail guide
# 7D 2M high precision gear transmission
# France Schneider electronics
# High-soft shielded cables
# Serrate working platform
# exhaust fan
# Lubricating system
# AC380V/50HZ/3 phase
| Parameters | Standard Specifications |
| Cutting width | 5000mm |
| Cutting length | 10000mm |
| Running speed | 0-8000mm/min |
| Torch lifting | ≤200mm |
| Precision standard | JB/T5102-1999 |
| Automatic lifting precision | ±0.5mm |
| Linear positioning accuracy | ±0.5mm/1000mm |
| Linear repositioning accuracy | ±0.5mm/1000mm |
| Mechanical line drawing accuracy | ≤±0.5 |
| Speed error | ±5% |
| Cutting roughness | Ra≤12.5μm |
Application industry:
Advertising, Metal fabrication, kitchenware, components, decorations industry.
Application material:
Stainless steel, mild steel, brass, copper, aluminum alloy, sheet metal, spring steel, gold, silver, etc
